JavaScript Timeline Plugin

JavaScript Timeline

Pico Library

Built on CalendarJS Timeline: This reactive timeline component is powered by CalendarJS Timeline, the core lightweight timeline engine (2.1KB gzipped) with advanced features. LemonadeJS adds reactive data binding and framework integration (Vue, React, Angular) on top of the CalendarJS foundation.

The LemonadeJS JavaScript Timeline is a framework-agnostic plugin designed for timeline creation, supporting Vue, React, and Angular integration. It facilitates the construction of logs, event timelines, and roadmaps, providing options for customization such as color adjustments, content modification, and control over point positioning. The plugin includes features for automatically grouping events by month and navigation controls, aiding in organizing and displaying timeline data.

Timeline Component Family

CalendarJS Timeline - Core Component

The underlying timeline engine powering this reactive wrapper. CalendarJS Timeline can be used standalone for non-reactive applications:

Lightweight: 2.1KB gzipped
Framework-agnostic: Works with vanilla JS, React, Vue, Angular
Full-featured: Monthly navigation, sorting, alignment controls
Customizable: Border styles, colors, positioning

Perfect for: Standalone timelines, event logs, project roadmaps, activity feeds

Explore CalendarJS Timeline

CalendarJS Schedule - Event Scheduling

For interactive drag-and-drop event scheduling instead of chronological lists, explore CalendarJS Schedule:

Day, week, and weekdays views
Drag & drop event management
Resource scheduling with time slots
Perfect for appointment systems and team calendars

Explore CalendarJS Schedule

When to Use Each

Component	Best For	Size	Reactive
LemonadeJS Timeline	Reactive Vue/React/Angular apps needing data binding	Pico	✓
CalendarJS Timeline	Standalone timelines, vanilla JS, non-reactive frameworks	2.1KB	-
CalendarJS Schedule	Interactive event scheduling with drag & drop	4.2KB	-

Documentation

Installation

npm install @lemonadejs/timeline

Configuration Options

Initialize the timeline with these settings to tailor the plugin to your specific needs:

Attribute	Description
`data: Item[]`	An array of items to be displayed. Each item follows the structure defined in Entry Attributes below.
`type?: 'monthly'`	Use `'monthly'` to enable month-based filtering and the navigation header. Omit for a flat timeline.
`value?: String\|Date`	Initial date used to seed the timeline (useful with `type: 'monthly'`). Accepts an ISO string or a `Date`.
`format?: String`	Mask used to render each item’s `day` label. Defaults: `dd mmm yyyy` (monthly), `dddd, dd` (otherwise).
`align?: String`	Align the bullet points. Accepted values: `"left"`, `"right"`, `"top"`, `"bottom"`. `Default: "left"`.
`order?: String`	`'asc'` for ascending or `'desc'` for descending. `Default: 'asc'`.
`message?: String`	Displayed when no items match. `Default: "No records found"`.
`width?: Number`	Container width in pixels.
`height?: Number`	Container height in pixels.
`controls?: Boolean`	Show the navigation header. Defaults to `true` when `type` is `'monthly'`, `false` otherwise.
`position?: String`	Passthrough for the `data-mode` attribute on the data container; a hook for custom CSS.
`url?: String`	URL for fetching data.
`remote?: Boolean`	When `true` together with `url` and `type: 'monthly'`, items are refetched on month/order change.
`onupdate?: Function`	Called every time `result` is recomputed. Signature: `(instance, result)`.
`onedition?: Function`	Called when the edit icon on an `editable` item is clicked. Signature: `(entry)`.

Entry Attributes

Define each timeline event with these specific properties to customize its appearance and behavior:

Attribute	Description
`date: String\|Date`	The item’s date. Required.
`title: String`	Main label for the item.
`subtitle?: String`	Secondary label shown under the title.
`description?: String`	Long-form description.
`borderColor?: String`	CSS color applied to the item’s border (`--lm-border-color`).
`borderStyle?: String`	CSS border style (`"solid"`, `"dashed"`, `"dotted"`, …); sets `--lm-border-style`.
`editable?: Boolean`	When `true`, renders an edit icon that fires `onedition`.
`tags?: Tag[]`	Array of tag chips rendered under the description. See Tag Attributes below.

Tag Attributes

Each entry under tags accepts:

Attribute	Description
`title: String`	Tag label.
`color?: String`	Background color applied to the chip (e.g. `'#dc2626'`, `'red'`).
`onclick?: Function`	Click handler. Signature: `(event, tag) => void`.

Instance API

Calling Timeline(root, options) returns an instance exposing:

Property / Method	Description
`el`	The root DOM element.
`data`	Reactive array of items (assign to replace).
`result`	Filtered + sorted array used for rendering.
`year` / `month`	Current navigation position (`month` is 1-12).
`months`	Localized month names.
`next()` / `prev()`	Navigate one month forward / backward.

Event Handling

Use these callbacks to monitor user interactions and to sync data with a server:

Event	Trigger
`onupdate?`	Fired after `result` is recomputed (initial render + every change). Signature: `(instance, result)`.
`onedition?`	Fired when the edit icon is clicked on an `editable` item. Signature: `(entry)`.

Examples

This section illustrates practical applications of the JavaScript timeline plugin, highlighting customization techniques for style and functionality to align with specific project objectives.

See more examples on https://codesandbox.io/p/sandbox/frosty-babycat-cjcwrk

Styling Attributes

Customize the visual aspects such as position, border style, and color schemes by setting the corresponding attributes during the initialization phase as demonstrated below:

live

<html>
<script src="https://cdn.jsdelivr.net/npm/lemonadejs/dist/lemonade.min.js"></script>
<script src="https://cdn.jsdelivr.net/npm/@lemonadejs/timeline/dist/index.min.js"></script>
<link rel="stylesheet" href="https://cdn.jsdelivr.net/npm/@lemonadejs/timeline/dist/style.min.css" />

<div id="root"></div>

<script>
const root = document.getElementById("root")

Timeline(root, {
    data: [
        {
            title: "Issue Identification",
            date: new Date(2022, 6, 1),
        },
        {
            title: "Root Cause Analysis",
            date: new Date(2022, 6, 2),
        },
        {
            title: "Implementation of Solution",
            date: new Date(2022, 6, 3),
            borderColor: '#808000',
            borderStyle: 'dashed',
        },
        {
            title: "Implementation of Solution",
            date: new Date(2022, 6, 4),
        }
    ],
    align: 'left'
})
</script>
</html>

import lemonade from 'lemonadejs'
import Timeline from '@lemonadejs/timeline';
import '@lemonadejs/timeline/dist/style.css';

export default function App() {
    const data = [
        {
            title: "Issue Identification",
            date: new Date(2022, 6, 1),
        },
        {
            title: "Root Cause Analysis",
            date: new Date(2022, 6, 2),
        },
        {
            title: "Implementation of Solution",
            date: new Date(2022, 6, 3),
            borderColor: '#808000',
            borderStyle: 'dashed',
        },
        {
            title: "Implementation of Solution",
            date: new Date(2022, 6, 4),
        }
    ];

    return render => render`<Timeline data="${data}" align="left" /></div>`
}

import React, { useRef } from 'react';
import Timeline from '@lemonadejs/timeline/dist/react';

export default function App() {
    const myRef = useRef();

    self.data = [
        {
            title: "Issue Identification",
            date: new Date(2022, 6, 1),
        },
        {
            title: "Root Cause Analysis",
            date: new Date(2022, 6, 2),
        },
        {
            title: "Implementation of Solution",
            date: new Date(2022, 6, 3),
            borderColor: '#808000',
            borderStyle: 'dashed',
        },
        {
            title: "Implementation of Solution",
            date: new Date(2022, 6, 4),
        }
    ];

    return (<div>
        <Timeline ref={myRef} data={data} align="left" />
    </div>);
}

<template>
    <Timeline :data="data" align="left" />
</template>

<script>
import Timeline from '@lemonadejs/timeline/dist/vue'

export default {
    name: 'App',
    components: {
        Timeline
    },
    data() {
        return {
            data: [
                {
                    title: "Issue Identification",
                    date: new Date(2022, 6, 1),
                },
                {
                    title: "Root Cause Analysis",
                    date: new Date(2022, 6, 2),
                },
                {
                    title: "Implementation of Solution",
                    date: new Date(2022, 6, 3),
                    borderColor: '#808000',
                    borderStyle: 'dashed',
                },
                {
                    title: "Implementation of Solution",
                    date: new Date(2022, 6, 4),
                }
            ]
        };
    },
}
</script>

<style>
</style>

Positioning Options

Configure the placement of the timeline on the page by choosing from four positions: left, right, bottom, or top. Adjustments can also be made programmatically, as shown in the following example:

live

<html>
<script src="https://cdn.jsdelivr.net/npm/lemonadejs/dist/lemonade.min.js"></script>
<script src="https://cdn.jsdelivr.net/npm/@lemonadejs/timeline/dist/index.min.js"></script>
<link rel="stylesheet" href="https://cdn.jsdelivr.net/npm/@lemonadejs/timeline/dist/style.min.css" />

<label for="dropdown">Choose a position to align:</label>
<select id="dropdown">
    <option value="left">Left</option>
    <option value="right">Right</option>
    <option value="top">Top</option>
    <option value="bottom">Bottom</option>
</select>
<div id="root"></div>

<script>
const root = document.getElementById("root")
const dropdown = document.getElementById("dropdown")


const tml = Timeline(root, {
    data: [
        { title: "Issue Identification", date: new Date(2022, 6, 1) },
        { title: "Root Cause Analysis", date: new Date(2022, 6, 2) },
        { title: "Implementation of Solution", date: new Date(2022, 6, 3) },
    ],
})

dropdown.addEventListener('change', (e) => {
    tml.align = e.target.value
})
</script>
</html>

import lemonade from 'lemonadejs'
import Timeline from '@lemonadejs/timeline';
import '@lemonadejs/timeline/dist/style.css';

export default function App() {

    let ref = null;

    const data = [
        { title: "Issue Identification", date: new Date(2022, 6, 1) },
        { title: "Root Cause Analysis", date: new Date(2022, 6, 2) },
        { title: "Implementation of Solution", date: new Date(2022, 6, 3) },
    ]

    const change = (e) => {
        ref.align = e.target.value;
    }

    return render => render`<div>
        <label>Choose a position to align:</label>
        <select onchange="${change}">
            <option value="left">Left</option>
            <option value="right">Right</option>
            <option value="top">Top</option>
            <option value="bottom">Bottom</option>
        </select>
        <Timeline data="${data}" :ref="${(e) => ref = e}" />
    </div>`
}

import React, { useRef } from 'react';
import Timeline from '@lemonadejs/timeline/dist/react';

export default function App() {
    const myRef = useRef();

    const data = [
        { title: "Issue Identification", date: new Date(2022, 6, 1) },
        { title: "Root Cause Analysis", date: new Date(2022, 6, 2) },
        { title: "Implementation of Solution", date: new Date(2022, 6, 3) },
    ];

    return (<>
        <label>Choose a position to align:</label>
        <select onChange={(e) => myRef.current.align = e.target.value}>
            <option value="left">Left</option>
            <option value="right">Right</option>
            <option value="top">Top</option>
            <option value="bottom">Bottom</option>
        </select>
        <div>
            <Timeline ref={myRef} data={data} />
        </div>
    </>);
}

<template>
    <label>Choose a position to align:</label>
    <select @change="this.$refs.timelineRef.current.align = $event.target.value">
        <option value="left">Left</option>
        <option value="right">Right</option>
        <option value="top">Top</option>
        <option value="bottom">Bottom</option>
    </select>
    <Timeline :data="data" ref="timelineRef" />
</template>

<script>
import Timeline from '@lemonadejs/timeline/dist/vue'

export default {
    name: 'App',
    components: {
        Timeline
    },
    data() {
        return {
            data: [
                { title: "Issue Identification", date: new Date(2022, 6, 1) },
                { title: "Root Cause Analysis", date: new Date(2022, 6, 2) },
                { title: "Implementation of Solution", date: new Date(2022, 6, 3) },
            ]
        }
    }
}
</script>

See this React Timeline example on codesandbox;
See this Vue Timeline example on codesandbox;

Monthly View Configuration

This setting enables a navigation control for monthly views, automatically grouping entries by their respective month and year.

live

<html>
<script src="https://cdn.jsdelivr.net/npm/lemonadejs/dist/lemonade.min.js"></script>
<script src="https://cdn.jsdelivr.net/npm/@lemonadejs/timeline/dist/index.min.js"></script>
<link rel="stylesheet" href="https://cdn.jsdelivr.net/npm/@lemonadejs/timeline/dist/style.min.css" />
<script type="text/javascript" src="https://cdn.jsdelivr.net/npm/[email protected]/build/build/faker.min.js"></script>
<link rel="stylesheet" href="https://fonts.googleapis.com/css?family=Material+Icons" />

<div id="root"></div>

<script>
const root = document.getElementById("root")

let data = [];
for (let i = 0; i < 500; i++) {
    data.push({
        date: faker.date.between(new Date(2025, 1, 1), new Date(2025, 12, 30)),
        title: faker.commerce.productName(),
        subtitle: faker.commerce.department(),
        description: faker.commerce.productName(),
    })
}

const timeline = Timeline(root, {
    data: data,
    type: 'monthly',
    align: 'left',
    width: 500,
    height: 500,
})
</script>
</html>

import lemonade from 'lemonadejs'
import Timeline from '@lemonadejs/timeline';
import { faker } from '@faker-js/faker';

import '@lemonadejs/timeline/dist/style.css';

export default function App() {
    const self = this;

    const data = [];
    for (let i = 0; i < 500; i++) {
        data.push({
            date: faker.date.between({
                from: new Date(2025, 1, 1),
                to: new Date(2025, 11, 30)
            }),
            title: faker.commerce.productName(),
            subtitle: faker.commerce.department(),
            description: faker.commerce.productName(),
        })
    }

    this.data = data;

    return render => render`<Timeline data="${this.data}" width="${500}" height="${300}" type="monthly" />`
}

import React, { useRef } from 'react';
import Timeline from '@lemonadejs/timeline/dist/react';
import { faker } from '@faker-js/faker';

import '@lemonadejs/timeline/dist/style.css';

let data = [];
for (let i = 0; i < 10; i++) {
    data.push({
        date: faker.date.between({
            from: new Date(2025, 1, 1),
            to: new Date(2025, 11, 30)
        }),
        title: faker.commerce.productName(),
        subtitle: faker.commerce.department(),
        description: faker.commerce.productName(),
    })
}

export default function App() {
    const myRef = useRef();

    return (<Timeline ref={myRef} data={data} type="monthly" />);
}

<template>
   <Timeline :data="data" type="monthly" ref="timelineRef" />
</template>

<script>
import Timeline from '@lemonadejs/timeline/dist/vue'
import { faker } from '@faker-js/faker';

export default {
    name: 'App',
    components: {
        Timeline
    },
    data() {
        let data = [];
        for (let i = 0; i < 10; i++) {
            data.push({
                date: faker.date.between({
                    from: new Date(2025, 1, 1),
                    to: new Date(2025, 11, 30)
                }),
                title: faker.commerce.productName(),
                subtitle: faker.commerce.department(),
                description: faker.commerce.productName(),
            })
        }
        return {
            data: data
        }
    }
}
</script>

Sorting

Configure the timeline to display events in ascending or descending chronological order.

live

<html>
<script src="https://cdn.jsdelivr.net/npm/lemonadejs/dist/lemonade.min.js"></script>
<script src="https://cdn.jsdelivr.net/npm/@lemonadejs/timeline/dist/index.min.js"></script>
<link rel="stylesheet" href="https://cdn.jsdelivr.net/npm/@lemonadejs/timeline/dist/style.min.css" />

<label for="dropdown">Choose a sorting order:</label>
<select id="dropdown-order">
    <option value="asc">Asc</option>
    <option value="desc">Desc</option>
</select>

<div id="root"></div>

<script>
const root = document.getElementById("root")
const dropdown = document.getElementById("dropdown-order")

const tml = Timeline(root, {
    data: [
        { title: "Issue Identification", date: new Date(2022, 6, 1) },
        { title: "Root Cause Analysis", date: new Date(2022, 6, 2) },
        { title: "Implementation of Solution", date: new Date(2022, 6, 3) },
    ],
})

dropdown.addEventListener('change', (e) => {
    tml.order = e.target.value;
})

</script>
</html>

import { state } from 'lemonadejs'
import Timeline from '@lemonadejs/timeline';
import '@lemonadejs/timeline/dist/style.css';

export default function App() {

    let data = state([
        { title: "Issue Identification", date: new Date(2022, 6, 1) },
        { title: "Root Cause Analysis", date: new Date(2022, 6, 2) },
        { title: "Implementation of Solution", date: new Date(2022, 6, 3) },
    ])

    const sort = (e) => {
        this.ref.order = e.target.value
    }

    return render => render`<div>
        <label>Choose a sorting order:</label>
        <select onchange="${sort}">
            <option value="asc">Asc</option>
            <option value="desc">Desc</option>
        </select>
        <Timeline data="${data}" :ref="this.ref" />
    </div>`
}

import React, { useRef } from 'react';
import Timeline from '@lemonadejs/timeline/dist/react';

export default function App() {
    const myRef = useRef();

    const data = [
        { title: "Issue Identification", date: new Date(2022, 6, 1) },
        { title: "Root Cause Analysis", date: new Date(2022, 6, 2) },
        { title: "Implementation of Solution", date: new Date(2022, 6, 3) },
    ];

    return (<>
        <label for="dropdown">Choose a sorting order:</label>
        <select id="dropdown" onChange={(e) => myRef.current.order = e.target.value}>
            <option value="asc">Asc</option>
            <option value="desc">Desc</option>
        </select>
        <div style={{ height: '300px', width: '500px' }}>
            <Timeline ref={myRef} data={data} />
        </div>
    </>);
}

<template>
    <label for="dropdown">Choose a sorting order:</label>
    <select id="dropdown" @change="this.$refs.timelineRef.current.order = $event.target.value">
        <option value="asc">Asc</option>
        <option value="desc">Desc</option>
    </select>
    <div style="height: 300px; width: 500px">
        <Timeline :data="data" ref="timelineRef" />
    </div>
</template>

<script>
import Timeline from '@lemonadejs/timeline/dist/vue'

export default {
    name: 'App',
    components: {
        Timeline
    },
    data() {
        return {
            data: [
                { title: "Issue Identification", date: new Date(2022, 6, 1) },
                { title: "Root Cause Analysis", date: new Date(2022, 6, 2) },
                { title: "Implementation of Solution", date: new Date(2022, 6, 3) },
            ]
        }
    }
}
</script>
